CL-360 Marine
Survey grade for marine applications.
Unlock more detail at further distances than any other system designed for marine survey platforms.
Expand survey capabilities to capture data both above and below water.
Install the CL-360 Marine on a survey vessel and leverage standard sonar survey workflow tools, such as CARIS HIPS, for streamlined data collection and processing.
The range accuracy and resolution capabilities of the CL-360 Marine enable users to unlock more detail at greater distances compared to any other system designed for application on marine survey platforms.
Accuracy and Resolution
The CL-360 Marine is the only survey grade lidar designed for marine applications. What does survey grade mean – here are a few of the specifications that matter.
- 500 kHz pulse rate
- 250 lines/s
- 2mm range resolution
- 0.001 degree angular resolution
In practical terms for your survey that means:
- Better definition of structural components
- Finer detail in the point cloud to better support analysis
- Detecting smaller objects such as power lines.
Designed for Marine Applications
With an IP67 rating and corrosion resistant components the CL-360 Marine has been designed with the needs of marine survey platforms in mind.
At 3.5kg, the CL-360 marine can be integrated onto most Uncrewed Surface Vessels (USV) which are capable of being equipped with multibeam sonar. A 10m cable kit also allows the system to be easily mounted on crewed vessels.
Enhanced Coastal Mapping Range
The 490m range capability of the CL-360 Marine allows coastal mapping and shoreline verification data to be collected at further distances, staying out in safer and deeper water. While collecting channel data there is potential to capture both sides of channels of nearly 1km width in a single pass.
Range also becomes crucial when mapping wet surfaces while inspecting infrastructure. A wet surface can absorb up to 90% of the laser pulse energy, significantly reducing the range at which you can map a wet surface.
DOCUMENTS
FREQUENTLY ASKED QUESTIONS
What is the CL-360 Marine used for?
It’s a survey-grade terrestrial lidar system designed specifically for marine applications, including coastal mapping, shoreline verification, and infrastructure inspection.
What makes it “survey grade”?
The CL-360 Marine offers high precision with a 500 kHz pulse rate, 250 lines/sec, 2mm range resolution, and 0.001° angular resolution, enabling detection of fine structural details and small objects like power lines.
What is its maximum range?
The system can reach up to 490 meters, allowing data collection from safer, deeper waters and enabling full channel mapping in a single pass.
Can it be used on both crewed and uncrewed vessels?
Yes. It’s lightweight (3.5 kg) and compatible with Uncrewed Surface Vessels (USVs) and crewed vessels, thanks to its 10m cable kit.
How does it integrate with other survey systems?
It can be paired with multibeam sonar systems and integrated into hydrographic survey missions to enhance above-water data collection.
